86-97 Ford F-350 4X4 Pan Hard Frame Drop Bracket

$ 89.00

Part Number: FORD-PHBF-001-3inch
Sky's drop fabricated pan hard bracket for the solid axle F-350 4x4 86-97 trucks.

What it is? A new drop bracket for 3" or 4" inch front shackle reversals instead of the traditional 2 piece design that utilizes a factory bracket and a plate of steel to drop it off the frame.
Safer than combining multiple parts for a cleaner install.

Can also be used to correct for spring lifts as well. We do not have a good option for this part to fit larger lifts. Experience has shown the engine cradle to potentially come loose with extra leverage of massive drop brackets. We recommend our Ford CSKAPB-001 system at this point.

Fits factory frame holes, minor grinding on cross member may be required do to Ford stamping these parts and accuracy was not a major concern.

Laser cut 1/4" plate steel, CNC formed, tig and mig welded construction.

Shipped raw steel. Reuses factory hardware.

Choose from options available according to lift height and finish.

Fully made in the USA!
